Case Report

Unusual Case of Nasopharyngeal Carcinoma with Intracranial Metastasis without Direct Invasion

Aneesh KM¹* and Shahana N²

¹Specialist Radiologist, NMC Medical Center, UAE

² Specialist Radiologist, Amina Hospital, UAE

Submission: January 1, 2020; Published: January 09, 2020

*Corresponding author: Balamurugan Rajendran, Department of Sabah Neuro and Spine Centre, Queen Elizabeth Hospital, Sabah, Malaysia

How to cite this article: Balamurugan Rajendran, Pullivendhan Sellamuthu. Unusual Case of Nasopharyngeal Carcinoma with Intracranial Metastasis without Direct Invasion. J Head Neck Spine Surg. 2020; 4(1): 555630. DOI: 10.19080/JHNSS.2020.04.555630

Abstract

Intracranial metastasis from Nasopharyngeal Carcinoma (NPC) is an extremely rare occurrence, although direct intracranial invasion is not infrequent in patients with NPC at a locally advanced stage. Only a few patients have been reported in detail in the English literature. Here, we report a case of a man with left high parietal dural metastasis of NPC, detected 2 years after Completed Concurrent Chemoradiotherapy (CCRT).

Introduction

Nasopharyngeal Carcinoma (NPC) is a rare malignancy in Western countries but considered endemic in certain places such as southern China and Southeast Asia [1] In Malaysia, NPC is the fifth (4.9%) most common cancer among Malaysians and the third (8.1%) most common cancer among males [2]. Because of nasopharyngeal anatomical location, patients with locally advanced NPC, it is not infrequent that the primary tumor directly invades the intracranial sites such as cavernous sinus through the skull base. Distant metastases to Central Nervous System (CNS) either through hematogenous route or Cerebral Spinal Fluid (CSF) spread are rare and dural metastasis at parietal region is even extremely rarer [3]. In this article, we report a rare of an elderly man with left parietal dural metastasis from NPC.

Case Report

A 65-year-old male was diagnosed with T2N1M0-Stage II NPC (American Joint Committee on Cancer (AJCC, 7 edition)) back in 2015. A Magnetic Resonance Imaging (MRI) scan and fiber optic endoscopy revealed a small primary tumor in left lateral nasopharynx and the biopsy revealed undifferentiated carcinoma of the nasopharynx. There was no intracranial extension but presence of metastatic lymph node measuring 1.5cm in greatest dimension over right neck. Three cycles of cisplatin based combined chemotherapy regimen (cisplatin, 5-flourouracil) were given prior to radiotherapy and a complete response was obtained at both primary site and in the neck. The nasopharynx and regional lymphatics were treated to a total dose of 34 fractionwith conventional radiotherapy regimen. He subsequent received a Concurrent Chemoradiotherapy (CCRT), which was finally completed in May 2017. Patient had been on surveillance follow up with Oncology team since then.

He remained well until 2 years after the conclusion of the radiotherapy, when he presented with pain over the left chest region for which a Computed Tomography (CT) Thorax was performed at a private center. On assessment, there was no neurological deficit elicited during that time. On CT imaging, there was nodular left pleural thickening with enhancement with metastasis lesions in thoracic vertebral bodies. Fluorodeoxyglucose positron emission computed tomography (FDG-PET/CT) scan was done for detailed workup, revealed pathological uptakes at the left nasopharynx, left pleural, left lung and a new hypermetabolic hyperdense mass in left higher parietal lobe, measuring 4.5 x 3.2 cm in size (Figure 1). The extra axial mass enhanced homogenously at a contrasted enhance CT with minimal edema (Figure 2). Radiologically unable to rule out possibility of a convexity meningioma arising from left parietal dura. The brain lesion was excised totally with a craniotomy and pathological examination revealed metastatic undifferentiated carcinoma (WHO Grade III).

On microscopic examination, the tumor shows fragments of cellular tissue infiltrated by malignant tumor arranged in syncytial pattern of cohesive cells with indistinct cell margins. The cells were large, pleomorphic with hyperchromatic nuclei, prominent nucleoli and moderate amount of cytoplasm. There was focal necrosis, and high mitosis. Immunohistochemical study revealedthat the tumor cells showed membranous CK 5/6 (Cytokeratin 5/6) immunoreactivity (Figure 3&4). Original diagnosis of the nasopharyngeal mass made in 2015 was confirmed to be undifferentiated nasopharyngeal carcinoma, which has similar morphological characteristics as the metastatic carcinoma to the brain. Post-operative, he was right hemiplegic secondary to infarct with hemorrhagic transformation. Patient was opted for palliative care in view next line of chemotherapy is high risk for the patient with current poor performance status.

Discussion

Even though intracranial invasion by direct extension of locally advanced disease is not uncommon, metastases to the CNS, either through hematogenous route or through the Cerebrospinal Fluid (CSF), from NPC have rarely been reported. Metastatic lesions to occipital and temporal lobes have been reported in some cases but for this gentleman, metastatic lesion was located near the parietal lobe [4, 5]. There is no known lymphatic or vascular connection between the nasopharynx and parietal lobes. Ngan and colleagues, discussing the same issue for the patients who had occipital metastases, hypothesized that microenvironment in the occipital lobes might have facilitated the metastatic tumor cells to localize in that region [5]. This case has shown that the occipital lobe and temporal are not the only sites for NPC cells to metastasize, thus make this case the first to be reported of a parietal dural metastasis from NPC. The incidence of recurrence of NPC has been reported as high as 77.5% following a remission, in which 48.1% occurs after 2 years while 17.4% recurred after 7-12 months [6]. Concurrent Chemoradiotherapy (CCRT) is the most potent treatment combination for locoregional control as well as improve overall survival for the advanced disease [7]. However, the impact of CCRT upon distant control was inadequate [8]. As for this case even with a good locoregional control post CCRT, yet after 2 years patient develop new distant metastasis to lung, vertebral bodies and brain. The 5-year overall survival rate of non-metastatic locoregionally advanced NPC treated with radiotherapy is reportedly up to just 60%, while the presence of distant metastases decreases it further to be around 12-15 months at best, after chemotherapy [9].

Status of primary tumor, evidences of disseminated disease, performance status of the patient, treatment modalities already applied to the patient, histopathology of the tumor, and symptoms related to brain metastases are the factors effecting the therapeuticmanagement. Since there was locoregional recurrence and patient was hemiplegic after operation, palliative care was planned for this patient. Palliative chemotherapy was not given in view his family members refused. In conclusion, due to the rarity of dural metastasis from the NPC, a high index of suspicion should be practiced where 6 monthly or yearly radiological assessments should be performed to rule out distant metastases including a CT scan of the brain.

References

1. Bray F, Ferlay J, Soerjomataram I, Siegel RL, Torre LA (2018) Global cancer statistics 2018: GLOBOCAN estimates of incidence and mortality worldwide for 36 cancers in 185 countries. CA Cancer J Clin 68(6): 394-424.
2. Azizah Ab M, Nor Saleha IT (2016) Malaysia national cancer registry report 2007-2011. Ministry of Health Putrajaya Malaysia.
3. Laigle-Donadey F, Taillibert S, Mokhtari K, Hildebrand J, Delattre JY (2005) Dural metastasis. J Neurooncol 75(1): 57-61.
4. Özyar E, Gözde Y, Gaye T, Aysenur C, Osman EÖ (2004) Undifferentiated nasopharyngeal carcinoma with isolated central nervous system metastasis. Archive of Oncology 12(2): 121-123.
5. Ngan RKC, Yiu HHY, Cheng HKM, Chan JKC, Sin V, et al. (2002) Central nervous system metastasis from nasopharyngeal carcinoma. A report of two patients and review of the literature. Cancer 94(2): 398-405.
6. Jia-Xin Li, Tai-Xiang Lu, Ying Huang, Fei Han (2011) Clinical characteristics of recurrent nasopharyngeal carcinoma in high-incidence area. Scientific World J 2012: 1-8.
7. Lee AWM, Lin JC, Ng WT (2012) Current management of nasopharyngeal cancer. Semin Radiat Oncol 22(3): 233-244.
8. Hui EP, Ma BB, Leung SF, King AD, Mo F, et al. (2009) Randomized phase II trial of concurrent cisplatinradiotherapy with or without neoadjuvant docetaxel and cisplatin in advanced nasopharyngeal carcinoma. J Clin Oncol 27(2): 242-249.
9. Loong HH, Ma BB, Chan AT (2008) Update on the management and therapeutic monitoring of advanced nasopharyngeal cancer. Hematol Oncol Clin North Am 22(6): 1267-1278.
