Chiari Malformation Type III with Good Outcome: Case-Report and Review of Clinical and Radiological Findings
Hosein Safari*, Ali Amiri and Akram Zare
Department of Neurosurgery, Golestan Hospital & Ahvaz Jundishapur University of Medical Sciences, Iran
Submission: February 17, 2018; Published: March 05, 2018
*Corresponding author: Hosein Safari, Department of Neurosurgery, Golestan Hospital & Jundishapur University of Medical Sciences, Ahwaz, Iran, Tel: 986133743032; Email: hoseinsafsari1382@gmail.com
How to cite this article: Hosein Safari, Ali Amiri, Akram Zare. Chiari Malformation Type III with Good Outcome: Case-Report and Review of Clinical and Radiological Findings. J Head Neck Spine Surg. 2018; 2(3): 555590. DOI: 10.19080/JHNSS.2018.02.555590
Abstract
Chiari III malformation, one of the rare variants of Chiari malformations, is including a small dysplastic posterior fossa, hydrocephalus, medullary abnormalities, and hindbrain herniation into a low occipital/high cervical encephalocele. This type can be lethal if not treated and is related to severe neurological deficits, so surgical care should immediately be undertaken. We are presenting a 1.5-month-old male infant with Chiari III malformation that was managed surgically with good outcome in addition, review the radiological, clinical and pathogenesis of Chiari III malformation.
Introduction
Type III Chiari malformation is a very rare condition that is described by Chiari in 1891.This type of Chiari defined as hindbrain herniation into a high cervical encephalocele or low occipital, and osseous defects with features of type II Chiari malformation (including a small posterior fossa, herniated dysplastic posterior fossa content, hydrocephalus, medullary kinking, and tectal beaking) [1-5]. In literature, approximately 60 cases have been reported since 1891 to have Chiari III (Table 1).
Chiari III malformation is related to early mortality, if not being treated. Since it has a poor outcome, it is related to severe neurological deficits, developmental delays, and seizure in long term, if being survived [6]. We are presenting a 1.5-month-old case of Chiari type III that was managed surgically with good outcome. In addition, review the pathogenesis, radiological, and clinical features of Chiari III malformation.
Case
A 1.5-month-old male infant presented to hospital emergency department with complaint of large congenital occipital mass. He was born at full-term, as the product of normal delivery, second child of a low socioeconomic non-consanguineous parents. There was no history of medication or maternal infection. The mother had no history of use of iron products, too. On examination, the child had 3350gr weight (wt.), 32 cm head circumference (H.C.) at birth, and 4000gr wt., 36cm H.C. at the day of admission. He had no neurological deformity or cranial nerve palsy, and had normal eye movement with no nystagmus. Spontaneous movements of all extremities were present. All reflexes were normal. Chest was clear, with normal breathing sound. There was a soft, 6*5cm trans-illuminate mass in occipital and upper cervical region, which was tense on crying and was covered with thin skin (Figure 1). There was no cerebrospinal fluid (CSF) leakage. There was no history of fever or discharge from the mass. The biochemical and hematological parameters were normal.
Magnetic Resonance Imaging (MRI) was performed on a 1.5T MR scanner and revealed a bony defect (approximately 2*2cm) in the occipital and upper cervical (C1-C2 vertebrae) region that had an encephalocele with partial herniation of the cerebellum and a part of the brainstem. There was no hydrocephalus (Figure 2-5). No tethering or syringomyelia was revealed in screening MRI of the lumbar spine.
After general anesthesia, the patient was turned prone. The skin over the mass was incised in midline and was dissected around the mass. Below the skin, the covering dura was seen. Suboccipital craniotomy was done. On opening the dura, herniated cerebellum was seen in the sac (Figure 6). Cord and brain steam was untethered and cranio-cervical junction adhesions were released. There was no need for ventrico- peritoneal shunt. Secondary closure of the dura was done with the pericranial patch. The child was extubated in the recovery room. Early post operation and on the fifth day brain computed tomography (CT) scan was done that didn't show hydrocephalus. Examination of lower cranial nerve was normal. Postoperative imaging revealed well positioned brain steam and cerebellum (Figure 7). Patient was discharged a week after surgery. Till now, 1 year after surgery, patient has good outcome with normal developmental and neurological examination.
Discussion
Hans Chiari, described and characterized hindbrain deformities as the Chiari malformation in 1891 [5]. One of the rare variants is Chiari malformation type III, that is characterized by osseous defects and occipital or high cervical encephalocele and some anatomical characteristics of Chiari malformation type II, including a small posterior fossa, herniated dysplastic posterior fossa content, hydrocephalus, medullary kinking, and tectal beaking [1-4]. Chiari malformation type III has poorer outcomes that type I and II, and those who survive develop with developmental delays and severe neurological deficit [6].
Till now, the pathogenesis of Chiari malformation type III remains unclear, but Chiari believed this variant was due to hydrocephalus [5]. Some have suggested that primary abnormal mesodermal defect is related to this type [7]. Some authors have stated that during intrauterine period, escape of CSF from an open neural tube defect has caused destination of primitive ventricles and small skull, like what happens in Chiari II malformation [8]. Others believe that caudal displacement of hindbrain and hypoplastic posterior fossa are the result of lack of distension of the embryonic ventricular system secondary to abnormal neurulation [4]. Others have posited that failure of ossification centers to fuse completely or failure of induction of endochondral bone by incomplete closure of the neural tube are responsible for bony defects and encephalocele [4,9]. Finally, some believe that mesenchymal development disturbance in embryological life is the secondary event in Chiari III malformation and the underlying problem is likely to be the deranged CSF dynamics [10].
Chiari III malformation incidence is 0.65-4.4% among all of the Chiari malformations [11-13] and have been diagnosed prenatally to 14-years-old [4]. The most common to the least position of encephalocele are low occipital/high cervical [14,15]. Symptoms are strongly related to the amount of herniated brain structures, ranges from asymptomatic in those with only bulging in the back of the head [16] to clinical findings like downbeat nystagmus and titubation, ataxia, sensory loss, respiratory failure, hyperreflexia, spastic muscle or hypotonia, and inspiratory stridor [17,18].
Occipital bone defects are seen in some, but not all Chiari III malformations [19], and 70% of cases have been reported to have incomplete fusion of the posterior arches of C1 [4]. Contents of encephalocele in Chiari malformation III is usually nonfunctional and contains necrosis of neural tissue, gliosis, fibrosis, meningeal inflammation, cerebral or cerebellar tissue, ventricles, and reactive astrocytes [6,15]. Cerebellum, occipital lobe, and parietal lobe are the most to the least common parts of brain occurring in the sac. Ectopic venous sinuses and aberrant deep veins are common [15]. Other anomalies of the brain are including posterior falx cerebri aplasia, lack of cerebellum, posterior petrous pyramids and the clivus scalloping, syringomyelia, and creeping of the cerebellar hemispheres around the brain stem [4,15]. Though hydrocephalus is not an essential finding, has been reported in 88% of the cases [6]. Syringomyelia is commonly present [16,18].
Ultrasound has been used antenatally, the earliest report is at 18 weeks of gestational age (WGA) [20], to identify cranial anomalies [3,21]. Elective C section is the standard plan of delivery when encephalocele diagnosed [20]. MRI is the modality of choice and can identify the amount of brain occurring in the encephalocele [6,15], and is used prenatally after abnormalities were seen on fetal ultrasound [20]. Though occipital/cervical encephalocele is not necessarily associated with a poor prognosis, Chiari III malformation can be lethal if untreated, so surgical care should be undertaken.
Time of surgery remains controversial, some believe that immediate closure of the defect is the ideal treatment while others believe if the sac is covered with normal skin, it is rarely needed to perform surgery urgently [6,16], but primary closure remains the treatment of choice [6,15]. Preserving neurological function while as much as possible neural tissue in the encephalocele is resected, reconstruction and repair of dura, and preventing future tethering are the goals of surgery [6,15]. Some authors report placing a temporary external drain [1], or a shunt before encephalocele closure [22-24]. Overall mortality rate is 29% [7,25], and postoperative mortality accounts for 22% of all mortalities [15]. Neurological function outcomes depend on the neurological status before surgery [24]. Positive prognostic factor is less than 5cm of herniated brainstem [6], and hydrocephalus, neural tissues in the sac, large size of sac, and intermittent respiratory stridor are the negative prognostic factors [7,18].
References
- Caldarelli M, Rea G, Cincu R, Di Rocco C (2002) Chiari type III malformation. Childs Nerv Syst 18(5): 207-210.
- Sirikci A, Bayazit YA, Bayram M (2001) The Chiari III malformation: an unusual and asymptomatic variant in an 11-year old child. Eur J Radiol 39(3): 147-150.
- Haberle J, Hulskamp G, Harms E, Krasemann T (2001) Cervical encephalocele in a newborn--Chiari III malformation. Case report and review of the literature. Childs Nerv Syst 17(6): 373-375.
- Cakirer S (2003) Chiari III malformation: varieties of MRI appearances in two patients. Clin Imaging 27(1): 1-4.
- Chiari H (1891) Ueber Veranderungen des Kleinhirns infolge von Hydrocephalie des Grosshirns. Dtsch Med Wochenschr 17(42): 11721175.
- Ijik N, Elmaci I, Silav G, Celik M, Kalelioglu M (2009) Chiari malformation type III and results of surgery: a clinical study: report of eight surgically treated cases and review of the literature. Pediatr Neurosurg 45(1):19- 28.
- Kiymaz N, Yilmaz N, Demir I, Keskin S (2010) Prognostic factors in patients with occipital encephalocele. Pediatr Neurosurg 46(1): 6-11.
- McLone DG, Knepper PA (1989) The cause of Chiari II malformation: a unified theory. Pediatr Neurosci 15(1): 1-12.
- Rani H, Kulkarni AV, Rao RV, Patil P (2013) Chiari III Malformation: a rare case with review of literature. Fetal Pediatr Pathol 32(3): 169-174.
- Lee R, Tai KS, Cheng PW, Lui WM, Chan FL (2002) Chiari III malformation: antenatal MRI diagnosis. Clin Radiol 57(8): 759-761.
- Cama A, Donati PT, Piatelli GL, Fondelli MP, Andreussi L (1995) Chiari complex in children--neuroradiological diagnosis, neurosurgical treatment and proposal of a new classification (312 cases). Eur J Pediatr Surg 5 Suppl 1: 35-38.
- Mayr U, Aichner F, Menardi G, Hager J (1986) Computer-tomographical appearances of the Chiari malformations of the posterior fossa. Z Kinderchir 41 Suppl 1: 33-35.
- Dyste GN, Menezes AH, VanGilder JC (1989) Symptomatic Chiari malformations. An analysis of presentation, management, and longterm outcome. J Neurosurg 71(2): 159-168.
- Furtado SV, Anantharam BA, Reddy K, Hegde AS (2009) Repair of Chiari III malformation using cranioplasty and an occipital rotation flap: technical note and review of literature. Surg Neurol 72(4): 414-417.
- Castillo M, Quencer RM, Dominguez R (1992) Chiari III malformation: imaging features. AJNR Am J Neuroradiol 13(1): 107-113.
- Jaggi RS, Premsagar IC (2007) Chiari malformation type III treated with primary closure. Pediatr Neurosurg 43(5):424-427.
- Jeong DH, Kim CH, Kim MO, Chung H, Kim TH, et al. (2014) Arnold- Chiari malformation Type III With Meningoencephalocele: A Case Report. Ann Rehabil Med 38(3): 401-404.
- Muzumdar D, Gandhi S, Fattepurkar S, Goel A (2007) Type III Chiari malformation presenting as intermittent respiratory stridor: a neurological image. Pediatr Neurosurg 43(5): 446-448.
- Aribal ME, Gurcan F, Aslan B (1996) Chiari III malformation: MRI. Neuroradiology 38 Suppl 1: S184-S186.
- Smith AB, Gupta N, Otto C, Glenn OA (2007) Diagnosis of Chiari III malformation by second trimester fetal MRI with postnatal MRI and CT correlation. Pediatr Radiol 37(10): 1035-1038.
- Kannegieter LS, Dietrich RB, Pais MJ, Goldenberg TM (1994) Pediatric case of the day. Chiari III malformation. Radiographics 14(2): 452-454.
- Snyder WE, Luerssen TG, Boaz JC, Kalsbeck JE (1998) Chiari III malformation treated with CSF diversion and delayed surgical closure. Pediatr Neurosurg 29(3):117-120.
- Agrawal A, Mittal A, Kohali GB, Sampley S, Gupta A (2011) Chiari III malformation. Pediatr Neurosurg 47(4): 309-310.
- Ambekar S, Devi BI, Shukla D (2011) Large occipito-cervical encephalocele with Chiari III malformation. J Pediatr Neurosci 6(2): 116-117.
- Cesmebasi A, Loukas M, Hogan E, Kralovic S, Tubbs RS, et al. (2015) The Chiari malformations: a review with emphasis on anatomical traits. Clin Anat 28(2): 184-194.
