Forestry Biomass as Energy Source in Brazil
Túlio A S Vieira1,2*, Sónia A C Carabineiro2 and Paulo F Trugilho1*
1Science and Technology of Wood, Forest Sciences Department, UFLA - Federal University of Lavras, Brazil
2Laboratory of Catalysis and Materials (LCM), Associate Laboratory LSRE/LCM, Faculty of Engineering, University of Porto, Portugal
Submission: April 26, 2019; Published: May 21, 2019
*Corresponding author: Túlio A S Vieira, Science and Technology of Wood, Forest Sciences Department, UFLA - Federal University of Lavras, Av. Doutor Sylvio Menicucci, 1001 - Kennedy, Lavras - MG, 37200-000 - Brazil & Laboratory of Catalysis and Materials (LCM), Associate Laboratory LSRE/LCM, Faculty of Engineering, University of Porto, Rua Dr Roberto Frias s/n 4200-465 Porto, Portugal
How to cite this article: Túlio A S V, Sónia A C C, Paulo F T. Forestry Biomass as Energy Source in Brazil. Int J Environ Sci Nat Res. 2019; 19(2): 556013. DOI:10.19080/IJESNR.2019.19.556013
Abstract
The demand for renewable energy is growing around the world. The participation of biomass, for the direct combustion of wood, charcoal, agricultural residues, among others, becomes more expressive. This opinion paper reports on the use of biomass as an energy source in Brazil, particularly the Eucalyptus genus.
Keywords: Renewable energy; Combustion; Chemical and energetic characterization
Introduction
Planet Earth has a large potential for energy that can be obtained from renewable sources, including wind, solar, hydro and biomass sources [1]. These sources play an increasing role in the mitigation of greenhouse gas emissions and provide an increasing fraction of primary energy in the world. Renewable sources are expected to significantly increase their share of global primary energy by 2050 [2].
An energy source is considered as renewable when the natural conditions allow its replacement in the short term [3] and are derived directly or indirectly from solar energy [4]. Non-renewable energy sources are not restored by nature in a period compatible with its consumption [3]. In general, they are widespread technol ogy, but have a high environmental impact. It is noteworthy that many industrial activities are dependent on fossil fuels, and those are exhausting and highly polluting sources of energy. Therefore, investments in renewable energy sources are indispensable. Renewable sources account for about 14% of the world’s generated energy. Brazil’s energy matrix differs from the world average, although energy consumption from non-renewable sources is larger than renewable energy. Firewood and charcoal, hydraulic, sugarcane and other renewable derivatives, totalize 42.9%, close to half of the Brazilian energy consumption matrix (Figure 1) [5].
Biomass is an important source of energy in Brazil, as it is very abundant. It is an alternative source of energy that offers significant economic and environmental gains, as it contributes to reducing dependence on petroleum derived fuels [6]. According to the principles of sustainable development, the use of biomass for energy is recognized as a mitigation measure of global warming, as it replaces fossil fuels and decreases the emission of greenhouse gases [7].
Biomass is distinguished using several raw materials, with different technologies for processing and transformation, playing a fundamental role in the environmental, energy and socioeconomic context [8,9].
In the world context, concerning the raw materials used as biomass supply sources, firewood predominates as a source of energy, followed by wood derivatives, such as charcoal and forest residues [10]. However, in Brazil, the use of sugarcane by-products (40%), such as anhydrous and hydrated alcohol, as well as sugarcane bagasse, followed using firewood and charcoal (19%) is predominant [5].
Biomass energy can be obtained from biochemical, thermochemical and physicochemical processes. Currently, there are numerous technologies for this conversion, resulting in a diversity of products that can be solid, liquid and gaseous. According to Patel et al. [11], among the thermochemical processes, the three main technologies used are pyrolysis, gasification and direct combustion.
Eucalyptus Genus
The Eucalyptus genus, belonging to the Myrtaceae family, which occurs naturally in Australia, has around 700 species adapted to the most diverse climatic and soil conditions [12]. Due to its relevant amplitude of edaphoclimatic adaptation and to its large number of species, the eucalyptus culture implanted in Brazil has emerged as a promising alternative for multiple use of commercial forest plantations [13]. Figure 2 shows an image of Eucalyptus trees.
The Brazilian forest sector has grown in recent years, from the application of new technologies, such as the genetic improvement of forest species, in addition to environmental factors favorable to forestry. This improvement made Brazil stand out in the forest productivity of planted species [14].
In the year 2015, the total area of trees planted in Brazil was 7.8 million hectares. Of these, 5.6 million hectares were occupied by Eucalyptus plantations. The largest planted areas are in the states of Minas Gerais (24%), São Paulo (17%) and Mato Grosso do Sul (15%) [15].
The main species cultivated in Brazil are Eucalyptus grandis, Eucalyptus urophylla and Eucalyptus camaldulensis [15]. The most widespread hybrids in Brazil are from the cross Eucalyptus urophylla x Eucalyptus grandis. According to Gonçalez et al. [16], the objective of the crossbreeding between these two species is to obtain plants with high resistance to water deficit (characteristic of E. urophylla) and high potential of rooting and growth in the field (characteristics of E. grandis). Combining the inherent characteristics of the two species, we obtain a hybrid with good characteristics adaptive to the most different conditions.
When selecting the genetic material to use, besides the final use of the wood, the soil and climatic requirements must be considered, which depend on the technological characteristics [17].
Wood Combustion (Direct Burning)
Combustion is defined as a rapid chemical combination of oxygen with a combustible material, being an oxidation reaction. For energy purposes, direct combustion occurs mainly in stoves (cooking of food), ovens (metallurgy, for example) and boilers (like steam generation). Although very practical and sometimes convenient, the process of direct combustion is usually very inefficient. Other problems are the high humidity of the fuel material (20% or more in the case of firewood) and the low energy density of the fuel (firewood, straw, residues etc.) which makes it difficult to store and transport [18].
The combustion of wood is a complex process consisting of a sequence of homogeneous and heterogeneous reactions. The procedure takes place in six consecutive well defined stages: drying, volatile emission, ignition of volatiles, burning of volatiles in flame, extinction of the flame of volatiles and combustion of carbon residue [19].
The reaction for combustion of wood with air can be presented as follows:
In which,
1 – are products of complete oxidation: CO2, SO2, H2O. The sulfur content of the wood is always low, its value being negligible;
2 – Excess air (N2 + O2) and likely the moisture of the fuel and air;
3 – Gas products (CO + H2 + CH4) and solids (soot) of incomplete combustion;
4 – Non-combustible mineral fraction of biomass (ashes).
According to Brutti et al. [20], among the main chemical reactions of wood combustion, are the combustion of carbon and hydrogen, according to equations:
In addition to the use of biomass as a solid fuel for the energy conversion through direct burning, pyrolysis and gasification also appear as differentials for better handling and burning of fuel [21]. The gas resulting from the gasification process can be used in the generation of electric energy by means of internal combustion engines, boilers and steam generators for steam turbines [22].
Properties of wood that affect combustion (direct burning)
The quality of wood depends on the combination of physical, chemical, anatomical and mechanical characteristics of a tree or its parts that allow to define its best use. According to Vital et al. [23], wood characteristics, such as moisture, basic density, biomass dry mass and lignin mass, structural and elemental chemical composition, calorific value, volatile matter content, ash and fixed carbon are properties generally used in the determination of their energetic potential.
The energetic evaluation is carried out with the purpose of promoting the classification of superior genotypes, since they are relevant for decision making in the implementation of reforestation projects aiming at the use of biomass as an energy source. The attributes of wood serve to promote differentiation between genetic materials [24,25].
In addition to the genotype, several factors can affect wood properties. The conditions of the site, age, plant spacing, fertilization, silvicultural practices are known. It is necessary to know the interrelationships of these factors so that this raw material can be improved, since these factors cause considerable physiological changes in the tree and, consequently, alter its energetic properties [26].
Thus, the main properties of the wood aimed at energetic use are high basic density, high calorific value; high lignin content; low ash content and low humidity [27].
The basic density is considered as one of the most important parameters among the physical properties of wood, since it affects most of the other properties. Its effects, however, are interactive and difficult to assess alone [28]. The advantage of using wood with high basic density is to store higher energy content in a smaller volume, which also contributes to the increase of its energetic density [25,29].
The calorific value is an excellent parameter for evaluating the energy potential of biomass fuels [30]. Woods with high calorific value have the largest amount of energy available in the form of heat. However, it is necessary that the wood is previously dry, since much of the energy produced during the thermochemical process is directed to evaporate the free water present, reducing the energy potential [31].
Moisture is an important factor that must be considered in any biomass aimed at combustion, and it is always preferable to use wood with the lowest possible humidity [23]. The main effects of high humidity on wood aimed for energy are the reduction of useful calorific value, reduction of the temperature in the combustion chamber with consequent loss of equipment efficiency and productivity, increase in biomass consumption and atmospheric emissions [32].
Another factor relevant to energy use is energy density, defined as the amount of useful energy released by a fuel per unit volume when subjected to combustion. The knowledge of the energy density of a given biomass allows to evaluate its potential for energy generation, considering that loads with higher energy densities contribute positively to the optimization of transport and reduction of costs.
The chemical composition of the material is also very relevant for energy use, because when thermally degraded, wood undergoes a transformation process, in which all its primary components (cellulose, hemicellulose and lignin) are drastically altered, which affects the energetic properties [33].
For the energy production, it is desirable that the wood presents high levels of carbon and hydrogen and low levels of oxygen due to the correlations between these elementary components and the calorific value. High concentrations of oxygen in the biomass favor a decrease in the calorific value [34], while high levels of carbon and hydrogen contribute to an increase in the calorific value of biomass fuels [35].
According to Bufalino et al. [36], the extractives can be determinant in the choice of the wood use, because, besides influencing the organoleptic properties, they can affect several other properties, such as density, permeability, retractability and energetic value.
The wood extractives contain several chemical compounds, but they do not constitute the essential wood structure, for example, polyphenols, oils, fats, resins, starch and waxes. As its name says, it refers to what can be extracted by some process. The phenolic origin of some extractives may act to increase the calorific value of wood, due to the presence of high carbon content [37].
The immediate chemical analysis of an energy source provides the contents of volatile materials, fixed carbon and ash (residual material), which influence the burning properties of the fuel, since the volatile constituents burn rapidly and the fixed carbon burns more slowly [38].
The higher the ratio volatile materials/fixed carbon the greater the intensity of combustion. Volatile materials dissipate rapidly during combustion: the higher the volatile material content, the lower the ignition temperature of the biomass. Although biomass ignites faster, it will have reduced burning time, which contributes to the reduction of energy efficiency [39].
The content of volatile materials and fixed carbon is directly related to the calorific value, increasing the time of burning of the energy source. The volatile materials and the fixed carbon content of the wood are dependent on each other, since the percentage of ashes in their constitution is generally low [28,40].
Ashes or minerals are inorganic constituents that do not participate in the combustion process of the biomass, representing about 1% of the dry mass of wood. A high percentage of ash is harmful to the energetic purpose. Minerals are undesirable, therefore, a residue is formed, since they not degraded in the thermochemical process; consequently, they contribute to the reduction of the calorific value.
One of the important characteristics to select biomass that presents/displays energetic potential is its thermal stability. Techniques such as thermogravimetric analysis (TGA) make it possible to understand the decomposition of biomass as a function of heating in thermochemical conversion processes [41]. The thermogravimetric analysis consists of analyzing the variation of the mass of samples in a system under the control of temperature and atmosphere, which can vary both with temperature and time, allowing to obtain information on composition, thermal stability, as well on the ranges of temperatures at which decomposition is more pronounced [42].
The evaluation of the energetic properties and efficiency of the material allows to obtain more competitive materials compared to other sources of energy. The energy density is an important parameter to be determined, since it influences the transport of the material, the amount of biomass consumed in the burning process and the size of the biomass storage silo of a machine, when the amount of energy required is associated with the characteristics of the material [43-45].
Conclusion
Waste Wood biomass, particularly the Eucalyptus genus, have are a good energy source in Brazil. The wood must have certain properties in order to show efficiency in the direct burning (combustion) process.
Acknowledgment
To Coordenação de Aperfeiçoamento de Pessoal de Nível Superior (CAPES), Conselho Nacional de Desenvolvimento Científico e Tecnológico (CNPq), Fundação de Amparo à Pesquisa do Estado de Minas Gerais (FAPEMIG) and LCM (Laboratory of Catalysis and Materials), FEUP (Faculty of Engineering - University of Porto) for supporting this study. We acknowledge FCT (Fundação para a Ciência e Tecnologia) for financial support (IF/01381/2013/ CP1160/CT0007, Investigador FCT program), with financing from the European Social Fund and the Human Potential Operational Program. This work was financially supported by Associate Laboratory LSRE-LCM - UID/EQU/50020/2019 - funded by national funds through FCT/MCTES (PIDDAC).
References
- Li Y, Zhou LW, Wang RZ (2017) Urban biomass and methods of estimating municipal biomass resources. Renewable & Sustainable Energy Reviews 80: 1017-1030.
- IEA - International Energy Agency (2015) Renewable Energy Medium- Term Market Report 2015: Market Analysis and Forecasts to 2020. pp. 1-8.
- Goldemberg J, Lucon O (2007) Energia e meio ambiente no Brasil. Estudos Avançados 21(59): 7-20.
- Braga B, Hespanhol I, Conejo JGL, Barros de MTL, Spencer M, et al. (2005) Introdução à engenharia ambiental. São Paulo: Prentice Hall, Brazil.
- Empresa De Pesquisa Energética – EPE (2018) Balanço Energético nacional 2018: Ano base 2017. 294 f. Rio de janeiro
- Chaves LI, Da Silva MJ, Souza SNM, Secco D, Rosa HA, et al. (2016) Small-scale power generation analysis: Downdraft gasifier coupled to engine generator set. Renewable & Sustainable Energy Reviews 58: 491-498.
- Staples MD, Malina R, Barrett SRH (2017) The limits of bioenergy for mitigating global life-cycle greenhouse gas emissions from fossil fuels. Nature Energy 16202.
- Cortez LAB, Lora EES, Gómez EO (2008) Biomassa para Energia. São Paulo: UNICAMP, Brazil.
- Vieira GEG, Nunes AP, Teixeira LF, Colen AGN (2014) Biomassa: uma visão dos processos de pirólise. Revista Liberato 15(24); 105-212.
- IEA - International Energy Agency (2009) Bioenergy - a Sustainable and Reliable Energy Source A review of status and prospects. p. 109.
- Patel M, Zhang X, Kumar A (2016) Techno-economic and life cycle assessment on lignocellulosic biomass thermochemical conversion technologies: a review. Renewable & Sustainable Energy Reviews 53: 1486-1499.
- Boscardin PMD, Almeida MA, Nakashima T, Paula JFP, Kanunfre CC, et al. (2012) Essential oil from Eucalyptus benthamii Maiden et Cambage reduces nitric oxide production in lipopolysaccharide-induced murine peritoneal macrophages. Acta Farmaceutica Bonaerense 31(4): 545- 548.
- Coutinh JLB, Santos VPD, Ferreire RLC, Nascimento JCB (2004) Avaliação do comportamento de espécies de Eucalyptus spp. na Zona da Mata Pernambucana. I: Resultados do primeiro ano - 2001. Revista Árvore 28(6): 771-775.
- Torres PMDA, Paes JB, do Nascimento JWB, Brito FMS, et al. (2016) Caracterização Físico-Mecânica da Madeira Jovem de Eucalyptus camaldulensis para Aplicação na Arquitetura Rural. Floresta e Ambiente 23(1): 109-117.
- IBÁ - Indústria Brasileira de Árvores (2017) Anuário estatístico da IBA: ano base 2016, p. 80.
- Gonçalez JC, Santos GL, Silva FG, Martins IS, Costa JA (2014) Relações entre dimensões de fibras e de densidade da madeira ao longo do tronco de Eucalyptus urograndis. Scientia Forestalis (IPEF) 42: 81.
- Trugilho PF, Goulart SL, de Assis CO, Couto FBS, Alves ICN, et al. (2015) Características de crescimento, composição química, física e estimativa de massa seca de madeira em clones e espécies de Eucalyptus jovens. Ciência Rural.
- Aneel - Agência Nacional De Energia Elétrica (2005) Atlas Energia Elétrica do Brasil. Panorama.
- Nogueira LAH, Lora EES (2003) Dendroenergia: fundamentos e aplicações. 2. ed. Rio de Janeiro: Interciência.
- Brutti RC, Brand MA, Simioni FJ, Neves AMD (2009) Estudo da viabilidade técnica do aproveitamento dos gases da combustão de biomassa na secagem de serragem para a geração de energia. Relatório de Projeto de Pesquisa: Adequação do uso de resíduos de madeira de pequena granulometria para a geração de energia. pp. 10.
- Demirbaş A (2001) Biomass resource facilities and biomass conversion processing for fuels and chemicals. Energy Conversion and Management 42(11): 1357-1378.
- Mourad AL, Ambrogi VS, Guerra SMG (2004) Potencial de utilização energética de biomassa residual de grãos. In: An. 5. Encontro de Energia no Meio Rural (AGRENER-GD), UNICAMP: Campinas-SP.
- Vital BR, Carneiro AC, Pereira BL (2013) Qualidade da madeira para fins energéticos. In: Santos F (Ed.), Bioenergia e biorrefinaria: cana de açúcar e espécies florestais. Viçosa, MG: O Editor; pp. 322-354.
- Lima EA de, Silva HD da, Lavoranti OJ (2011) Caracterização dendroenergética de árvores de Eucalyptus benthamii. Pesquisa Florestal Brasileira 31(65).
- Trugilho PF, Silva DA (2001) Influência da temperatura final de carbonização nas características físicas e químicas do carvão vegetal de jatobá (Himenea courbaril L.). Scientia Agrária 2(1-2): 45-53.
- Latorraca JV de F, Albuquerque CEC (2000) Efeito do rápido Crescimento sobre as propriedades da madeira. Floresta e Ambiente 7(1): 279-291.
- Protásio T de P, Bufalino L, Tonoli GHD, Couto AM, Trugilho PF, et al. (2011) Relação entre o poder calorífico superior e os componentes elementares e minerais da biomassa vegetal. Pesquisa Florestal Brasileira 31(66).
- Pereira MPCF, Costa EVS, Pereira BLC, Carvalho AMML, Carneiro ACO, et al. (2016b) Torrefação de cavacos de eucalipto para fins energéticos. Pesquisa Florestal Brasileira 36(87): 269-275.
- Pereira JCD, Turion JA, Higa AR, Higa RCV, Shimizu JY (2000) Características da madeira de algumas espécies de eucalipto plantadas no Brasil. Embrapa Florestas, pp. 1-112.
- Marafon AC, Santiago AD, Amaral AFC, Bierhals AN, Paiva HL, et al. (2016)Poder Calorífico do Capim-Elefante para a Geração de Energia Térmica. Aracaju: Embrapa Tabuleiros Costeiros.
- Pimenta AS, Barcellos DC, Oliveira E (2010) Carbonização. Viçosa: Universidade Federal de Viçosa, p. 94.
- Wiecheteck M (2009) Aproveitamento de resíduos e subprodutos florestais, alternativas tecnológicas e propostas de políticas ao uso de resíduos florestais para fins energéticos. pp. 1-40.
- Yu J, Paterson N, Blamey J, Millan M (2017) Cellulose, xylan and lignin interactions during pyrolysis of lignocellulosic biomass. Fuel 191: 140- 149.
- Huang C, Han L, Liu X, Yang Z (2009) Ultimate analysis and heating value prediction of straw by near infrared spectroscopy. Waste Management 29(6): 1793–1797.
- Demirbas A (2004) Relationships between Heating Value and Lignin, Moisture, Ash and Extractive Contents of Biomass Fuels. Energy Exploration & Exploitation 20(1): 105-111.
- Bufalino L, Protásio TP, Couto AM, Nassur OAC, Trugilho PF, et al. (2012) Caracterização química e energética para aproveitamento da madeira de costaneira e desbaste de cedro australiano. Brazilian Journal of Forestry Research 32(70): 129-137
- Rowell RM (2005) Chemical modification of wood. In: Rowel RM (Ed.), Handbook of wood chemistry and wood composites. CRC Press, Boca Raton, pp. 381-420,
- Fernandes ERK, Marangoni C, Souza O, Sellin N (2013) Thermochemical characterization of banana leaves as a potential energy source. Energy Conversion and Management 75: 603-608.
- García R, Pizarro C, Lavin AG, Bueno JL (2013) Biomass proximate analysis using thermogravimetry. Bioresource Technology 139: 1–4.
- Chaves AMB, do Vale AT, Melido RCN, Zoch VP (2013) Características energéticas da madeira e carvão vegetal de clones de Eucalyptus spp. Enciclopédia Biosfera 9(17): 533-542.
- Carneiro A de C O, et al. (2013) Estudo da decomposição térmica da madeira de oito espécies da região do Seridó, Rio Grande do Norte. Revista Árvore 37(6): 1153-1163.
- Yeo JY, Chin BLF, Tan JK, Loh YS (2017) Comparative studies on the pyrolysis of cellulose, hemicellulose, and lignin based on combined kinetics. Journal of the Energy Institute 92(1): 27-37.
- Pereira BLC, Carvalho AMMLC, Oliveira AC, Santos LC, Carneiro A de CO, et al. (2016a) Efeito da carbonização da madeira na estrutura anatômica e densidade do carvão vegetal de Eucalyptus. Ciência Florestal 26(2): 545-557.
- Brito JO, Barrichelo LEG (1977) Correlações entre características físicas e químicas da madeira e a produção de carvão vegetal: I . Densidade e teor de lignina da madeira de eucalipto. IPEF 14: 9-20.
- Sathaye J, Lucon O, Rahman A, Christensen J, Denton F, et al. (2011) Renewable Energy in the Context of Sustainable Energy. In: IPCC Special Report on Renewable Energy Sources and Climate Change Mitigation, Cambridge University Press, Cambridge, United Kingdom and New York, NY, USA.
