Giant Rheumatoid Synovial Cyst of the Plantar Foot: Review and Case Report
Ronald Troxell* and Carl Kihm
Department of Podiatry, Norton Audubon Hospital, USA
Department of Podiatry, University Foot and Ankle, USA
Submission: January 12, 2018; Published: February 13, 2018
*Corresponding author: Department of Podiatry, Norton Audubon Hospital, 1 Audubon Hospital Louisville, KY 40217, USA, Email: rtroxell5@ gmail.comw
How to cite this article: Ronald T, Carl K. Giant Rheumatoid Synovial Cyst of the Plantar Foot: Review and Case Report. Ortho & Rheum Open Access 2018; 10(4): 555791. DOI: 10.19080/OROAJ.2018.10.555791.
Introduction
Rheumatoid arthritis (RA) is a chronic, systemic, autoimmune disorder of unknown etiology. The condition is characterized by the degree of joint destruction, deformity and disability that it causes. The RA disease process begins in the synovial membrane of joints. Initially, the synovial tissue undergoes immune-mediated microvascular injury (venous distension, capillary obstruction and thrombosis, and peri-vascular hemorrhage) [1]. This results in a rheumatoid pannus - synovial tissue edema and synovial cell proliferation. The swollen, hypertrophied synovium protrudes into the surrounding joint where an immune-mediated cascade of events releases hydrolytic enzymes, oxygen radicals and arachidonic acid metabolites [1]. This is directly responsible for joint destruction and peri-articular tissue damage. Rheumatoid foot manifestations are frequent and occur in up to 90% of RA patients [2]. Peri-articular tissue damage results in laxity of the joint-stabilizing ligaments and tendons. Severe hallux valgus with lateral dislocation of the lesser MPJs is common. The ankle and rear foot could alternatively been affected. These manifestations are usually bilateral and symmetrical. As the involved joints are destructed and dislocations ensue, localized plantar pressures can lead to the development of a cyst, bursa or Rheumatoid nodule [2].
Rheumatoid nodules are the most common extra-articular RA manifestation, occurring in 30-40% of RA patients [3]. Nodules can develop on any tendon, ligament, fascia or periosteum [4]. Since these tend to occur in pressure-bearing areas, they can become inflamed, infected or debilitating; however, nodules are generally asymptomatic and are therefore not treated. When nodules affect daily living, the following options are considered: padding/offloading, disease-modifying anti-rheumatic drugs, corticosteroid injection and surgical excision [3]. Nodules can be difficult to differentiate from less common neoplasm's and pseudo-tumor soft tissue lesions [5]. Definitive diagnosis is confirmed with biopsy. Here, we present a case report of a rare, giant Rheumatoid-associated synovial cyst in a foot.
Case Report
An 82 year old Caucasian female presented to the emergency department with right lower extremity infection. Her medical history included RA, COPD, CAD, PAD, early dementia and gout. At presentation, she had been ambulatory with a walker due to her chronic rear foot dislocation. Her WBC was 18.9. Her ABIs were falsely elevated and toe pressures were adequate for healing. Her right plantar foot had an unusual appearance; (Figure 1). A softball-sized mass was located on the plantar medial rear foot. A 2.0 x 2.0 x 0.2 cm wound with a draining sinus communicated to the mass, initially believed to be a rheumatoid nodule. Her family explained that this mass was previously excised twice and has redeveloped slowly over several years. It had been removed due to infection (three and four years prior). After the both excisions, she had wound healing complications but eventually healed her last excision upon a lateral plantar artery flap procedure which was performed by a general surgeon. At the time of presentation, the recurring mass was the largest it had ever been. Previous pathology reports described the mass to be benign and fibrotic.
Radiographs were obtained for further evaluation. The plantar rear foot mass was obvious. Rheumatoid rear foot destruction and chronic peri-talar subluxation was severe; shown in Figure 2. An MRI was not possible now since she recently had a pacemaker implanted. Three years earlier, an MRI had been performed (prior to initial surgical excision); images shown in Figure 3. The patient was made aware of the risk for below knee amputation but elected limb salvage. She was consented for surgical excision and biopsy. A longitudinal excision was created along the course of the mass. Dissection was carried down to the deep fascial layer overlaying the giant mass.
The well-demarcated, encapsulated mass was gently dissected from the soft tissues and a stalk was traced to the dislocated talonavicular joint. The mass was excised in toto (measuring 10 x 10 x 6cm) and sent to pathology for analysis; Figure 4. Wound cultures were also obtained. Upon removing the giant mass, an overabundance of soft tissue was addressed via a 3:1 longitudinal elliptical excision along the length of the incision. A smaller transverse 3:1 elliptical incision was also performed at the midline of the longitudinal excision, creating a "T-shaped" closure. This closure effectively eliminated "dead space," allowed for wound excision and provided closure of the subcutaneous tissue and skin layers without significant tension. She was placed in a posterior splint and kept non-weight bearing as she continued to receive IV antibiotics.
Pathology reported that the mass was benign and was not a rheumatoid nodule. As shown in Figure 5, histology revealed hypertrophied synovial tissue with central cystic degeneration, consistent with a synovial cyst. The wound culture resulted as vancomycin-resistant enterococci and she was subsequently managed per Infectious Disease. Following surgical excision, her incision dehisced. She was managed with debridement and wound VAC application less than two weeks after mass excision. On two subsequent occasions, an Integra bilayer matrix graft was used to promote healing. Local wound care, splinting and non-weight bearing allowed her to progressively heal over the course of 8 months (Figure 6). She has not had a recurrence of the mass or infection after 15 months of follow-up. Due to her chronic peri-talar subluxation, she remains largely non-weight bearing. She wears a CROW device, rarely when limited weight bearing with a walker is necessary. There are no plans for surgical reconstruction.
Discussion
Severe rear foot dislocation and localized pressure to the talar head allowed for the development and recurrence of the mass. The mass was very large and impressive, and gradually evolved as a cushion to pad and protect the dislocated rear foot. The large size of the mass, itself, made the mass somewhat disabling as she could not place her foot flat on the ground. Over time, pressure to the mass caused it to break down, ulcerate and infection developed. Excision was not indicated until infection developed due to the benign history, the patient's co morbidities and past healing complications. At the time of presentation, the patient had a severe and worsening infection. In attempts to salvage her leg, excision was performed. In this setting, our patient was not suitable for reduction and fusion of her dislocated joints. In a more suitable patient, excision of the mass with joint fusion procedures may yield successful and more definitive outcome.
As expected, our patient again had difficulty healing. She was managed without post-operative infection or serious complication. Although her limb was salvaged, she remains largely non-ambulatory and must be mindful to offload her rear foot even when sitting in her wheelchair. Although she would presumably be more functional with a below knee amputation, she is very happy with her current outcome. We continue to monitor her. The mass previously recurred twice and it would not be surprising if it developed again. In a healthier patient with multiple recurrences, early excision may be preferred since the mass progressively becomes larger until debilitating or infection develops.
Rheumatoid nodules are the most common extra-articular manifestation of RA. Giant Rheumatoid-associated synovial cysts in the foot have only been reported once [6] in the literature according to our PubMed search. Giant synovial cysts are most common in the knee but only rarely reported with RA pressure- bearing joints: the hip [7], the shoulder [8], and in areas of dislocation (atlantoaxial subluxation) [9]. Although synovial tissue edema and proliferation is normal in RA, the development of such a giant synovial mass in the foot is rare in our experience and review.
Surgical excision is generally required when a giant synovial cyst of the foot becomes infected or disabling. Biopsy should be performed of any such mass as it provides a definitive diagnosis. Further understanding of the immune-modulated cascade of events leading to synovium hyperplasia and proliferation may allow for development of medications to inhibit these pathways. A recent study suggests that moxibustion, a traditional Chinese herb, has been shown to be effective in inhibiting these abnormal activation pathways (TLR 4-MyD 88-NF -kappa-B pathways) in synovial tissue of RA rats [10].
References
- Schumacher Jr, H Ralph (1988) Primer on the Rheumatic Diseases. Arthritis Foundation, Atlanta, GA, USA.
- The Foot and Rheumatoid Arthritis (2017) NRAS - National Rheumatoid Arthritis Society, Berkshire, England.
- Rheumatoid nodules (2017) UptoDate.
- Rheumatoid Nodules (2017) American Osteopathic College of Dermatology (AOCD), Missouri, USA.
- Van Hul (2011) Pseudotumoural soft tissue lesions of the foot and ankle: a pictorial review. Insights Imaging 2(4): 439-452.
- Bienenstock H (1975) Rheumatoid plantar synovial cysts. Ann Rheum Dis 34(1): 98-99.
- Patkar D, Shah J, Prasad S, Patankar T, Gokhale S, et al. (1999) Giant rheumatoid synovial cyst of the hip joint: diagnosed by MRI. J Post grad Med 45(4): 118.
- Ribeiro ES, Barcelos A (2009) Giant synovial Rheumatoid cyst of the shoulder. Acta Reumatol Port 34(4): 677-678.
- 9 Sheen JJ, Seo DK, Rhim SC (2013) Hemorrhagic synovial cyst associated with Rheumatoid atlantoaxial subluxation: Case report. Korean J Spine 10(2): 85-87.
- Yuan J, Hu L, Song XG, Tang ZL, Zhang CY, et al. (2015) Influence of moxibustion on TLR-4-MyD 88-NF-KB signal transduction pathway of synovial tissue in Rheumatoid arthritis rats. Zhen Ci Yan Jiu 40(3): 199-204.
