Extracellular Vesicles Release from Human Osteoarthritic Chondrocytes
Ilaria Giusti1, Marianna Di Francesco1, Annalisa Mancò2, Sandra D'Ascenzo1, Antonello Aloisi2 , Vittorio Calvisi2 and Vincenza Dolo1*
1Department of Life, Health and Environmental Sciences, University of L'Aquila, Italy
2Department of Life, Health and Environmental Sciences, Postgraduate School of Orthopaedics and Traumatology, University of L'Aquila, Italy
Submission: February 14, 2017; Published: March 02, 2017
*Corresponding author: Vincenza Dolo, Department of Life, Health and Environmental Sciences, University of L'Aquila, Via Vetoio-Coppito 2, I-67100, L'Aquila, Italy, Tel: +39 0862 433665; Fax: +39 0862 433425; Email: vincenza.dolo@univaq.it
How to cite this article: Giusti I, Di Francesco M, Manco A, D'Ascenzo S, Aloisi A, et al. Extracellular Vesicles Release from Human Osteoarthritic Chondrocytes. IInt J cell Sci & mol biol. 2017; 1(5): 555572. DOI:10.19080/IJCSMB.2017.01.555572
Abstract
Osteoarthritis (OA) is a degenerative disease which affects up to 40% of people aged over 65 years causing joint pain, stiffness/impaired mobility and having a significant negative effect on their quality of life. It is beginning to emerge that EVs could have a role in this disease pathogenesis: indeed, over the years the role of EVs as a mean of cell-to-cell communication has become increasingly clear and obvious; specifically, in OA it seems that chondrocytes and synoviocytes, the two most important cell types in joint biology, affect each other their behavior using EVs to mediate the exchange of information. In spite of this, the study of EVs released from these cells is very limited. Here we present a morphological analysis of EVs isolated from OA chondrocytes, showing both their release from cell surface (using Scansion Electron Microscopy) and their size and morphology (using Transmission Electron Microscopy); moreover, being known the role of enzymes in the degradation of the extracellular matrix associated to OA, we assessed the presence of Gelatinases and Plasminogen Activators associated to EVs.
Introduction
In recent years it has become more and more clear that both prokaryotic and eukaryotic cells are able to release, in extracellular medium, spherical membrane vesicles delimited by a lipid bilayer of various size and cell origin [1]. In relation to the latter two parameters currently is it possible to distinguish between: exosomes (EXOs) which originate from the endosomal compartment after fusion of multivesicular bodies with the plasma membrane and whose size is typically considered smaller than 100 nm in diameter; microvesicles (MVs) which are released by outward budding of cell membrane and have diameter between 100 and 1000 nm; apoptotic bodies (ABs) which are the larger vesicles, having a diameter greater than 1µm, and are released by cells undergoing apoptosis [2].
EVs, initially interpreted as cell debris or simply as a mechanism that cell used to discard useless components, are now believed to be a previously not recognized form of intercellular communication since they contain fully functional proteins, lipids and nucleic acids which travel protected between releasing and target cells, even in very distant places from the source site [1]; they, indeed, could be isolated from virtually all biological fluids included blood, saliva, urine, pleural effusions, ocular effluent and aqueous humor, nasal secretions, breast milk, amniotic fluid, cerebrospinal fluid, bile, semen and ascites [3].
The undeniable role in inter-cellular communication make EVs involved in many normal and pathological conditions: some examples of physiological functions include immune system functions [4], hemostasis and thrombosis [5], interneuronal communication [6], male [7] and female reproduction [8] whilst pathological processes mainly include cancer [9-11] but also malignancies of nervous system [12], rheumatoid arthritis and osteoarthitis [13]. The present paper briefly discloses the release of EVs (both MVs and EXOs) by human chondrocytes isolated from osteoarthritic joints.
Materials and Methods
Cell culture
Specimens of human OA articular cartilage were obtained from femoral cut (femoral condyles and intercondylar notch) of patients undergoing total knee replacement surgery. Written informed consent was obtained from all participants. For cells isolation cartilage was removed from the subcondral bone using a sterile sharp scalpel and placed in serum free DMEM (Dulbecco's Modified Eagle's Medium - High Glucose; EuroClone S.p.A., Pero (MI), Italy); once all cartilage was removed, slivers were further diced to improve the subsequent enzyme action. Enzymatic isolation was carried out by an overnight digestion in 1mg/ml Collagenase II (Collagenase Type II from Clostridium histolyticum; Gibco-ThermoFisher, Waltham, Massachusetts, USA) in DMEM supplemented with 10% heat-inactivated Fetal Bovine Serum (FBS - EuroClone).
After digestion, cell suspension was filtered on cell strainers (Falcon™ Cell Strainers, mesh size 70 µm; FisherScientific, ThermoFisher) to remove undigested debris and centrifuged (600 xg, 10 minutes, room temperature). Cells were then resuspended and plated in DMEM containing 1x Penicillin/ Streptomycin (Euroclone SpA), 2 mM L-Glutamine (Euroclone SpA), 10 mM Hepes (Sigma-Aldrich, St. Louis, MO, USA), 2,5 µg/ ml Amphotericin B (Sigma-Aldrich) and 10% FBS.
Isolation of EVs from conditioned medium
Human OA chondrocytes were stimulated with 5% of 40 nm- filtered FBS HyClone (Thermo Scientific, Rockford, IL, USA) in DMEM for 18 hours and then conditioned medium was collected. To isolate EVs, the conditioned medium obtained as above was centrifuged at 600 x g for 15 min and then at 1,500 x g for 30 min to remove cells and large debris, respectively. Supernatants were centrifuged at 100,000 x g for 2 h at 4°C in a Beckmann ultracentrifuge. Isolated vesicles were resuspended in Dulbecco's phosphate-buffered saline (EuroClone, Milan, Italy) for TEM analysis and protein content analysis. Double determination of vesicle quantification was carried out by measuring the vesicle- associated protein levels using the Bradford method (Bio-Rad, Milan, Italy) with bovine serum albumin (Sigma-Aldrich, St. Louis, MO, USA) as the standard.
Electron microscopy
Scanning electron microscopy (SEM) was performed on cells that were allowed to attach directly on coverslips, simultaneously to their isolation step. When cells were almost 70% confluent, samples were fixed with 2 % glutaraldehyde (Electron Microscopy Sciences, Hatfield, PA, USA) in phosphate- buffered saline (PBS) for 30 minutes, then dehydrated by subsequent exchanges of the following ethanol gradual series: 30, 50, 70, 90, and 100 % ethanol diluted in distilled water. Samples were critical point-dried, glued onto stubs, coated with gold in a SCD040 Balzer Sputterer, and observed using a Philips 505 SEM at 20 kV.
Transmission electron microscopy (TEM) was carried out on isolated EVs, resuspended in PBS, to analyze their ultrastructural morphology. According to proper dilutions, the samples were transferred on 300 mesh carbon-coated copper grids (Electron Microscopy Sciences, Hatfield, PA, USA) in a humidified chamber at room temperature and allowed to adsorb to the surface of the grids for 5 minutes. EVs on grids were then fixed in 2 % glutaraldehyde (Electron Microscopy Sciences, Hatfield, PA, USA) in PBS for 10 minutes and then briefly rinsed in Milli-Q water. The grids were kept wet on the side of the adsorbed EVs during all steps, but dry on the opposite side. To contrast the samples, grids were transferred on a drop of 2 % phosphotungstic acid, brought to pH 7.0 with NaOH, for 5 minutes. After negative staining the grids were left to dry and stored in appropriate grid storage boxes. Grids with adhered EVs were examined with a Philips CM 100 transmission electron microscope TEM at 80 kV and images were captured by a Kodak digital camera.
Zymography
Gelatin and casein-plasminogen zymography were performed on EVs released from OA chondrocytes.
Gelatin zymography was performed using sodium dodecyl sulfate-polyacrylamide gels (SDS-PAGE, 7.5%) copolymerized with 1 mg/mL of gelatin type B (Sigma Chemical Co.) whilst casein-plasminogen zymography was performed using SDS- PAGE 10% copolymerized with 0,2% casein (Sigma Aldrich, St. Louis, MO, USA) and 10 mg/ml plasminogen (Sigma Aldrich, St. Louis, MO, USA). EVs were diluted in an SDS-PAGE sample buffer in nonreducing conditions without heating; 10 µg and 15 µg of EVs were loaded for gelatin and casein-plasminogen zymography, respectively.
After electrophoresis, the gels were washed twice for 30 minutes in Tris 50 mM pH 7.4 plus 2.5% Triton X-100 at RT and incubated overnight in activating buffer (50 mM Tris-HCl, pH 7.4, containing 5 mM CaCl2 and 150 mM NaCl for gelatinases; Tris 50 mM pH 7.4 for plasminogen activators) at 37 °C. The gels were stained with Coomassie Blue R 250 (Bio-Rad, Hercules, CA) using a mixture of methanol-acetic acid-water (4:1:5) for 1 hour and were destained in the same solution without dye. The enzymes' activities were visualized as distinct bands, indicating the proteolysis of the substrate. Images recording and bands intensity quantification was carried out with the gel documentation system Alliance LD2 (UVItec, Cambridge, UK).
Results and Discussion
Osteoarthritis (OA) is a degenerative disease which affects the synovial joints; whole articulation, i.e. hyaline cartilage and subchondral bone, is involved. The pathology, in fact, is characterized by cartilage degradation, synovial inflammation and alteration of bone structure [13-15].
OA has a slow evolution, characterized by joint pain, stiffness/ impaired mobility and by significant negative effects on the quality of life. It is certainly the most common musculoskeletal disorder and cause of chronic pain in the elderly: up to 40% of people aged over 65 years typically has symptomatic OA of the knee or hip [14,16].
Currently, research in OA field is aimed at identify new approaches to stimulate the repair of damaged cartilage [14]; so, a deeper understanding of the biology of the cells involved, mainly represented by chondrocytes, could be helpful to this purpose.
The release of EVs from chondrocytes is not well documented, as well as their possible role in OA [13], even if it has been demonstrated that EVs are someway involved in the pathology acting as means of communication between synoviocytes and chondrocytes: EVs from chondrocytes treated with IL-ip when used to treat synoviocytes induced an increased production of MMP-13, which leads progression of OA [17] as well as EVs from fibroblast-like synoviocytes stimulated with IL-ip induce osteoarthritic changes in chondrocytes (up regulation of MMP- 13 and down regulation of collagen type 2 and aggrecan genes) [18]. To our best knowledge no morphological studies on EVs from OA chondrocytes have never been performed and this paper intends to fill this gap in this topic.
To such purpose, we used electron microscopy to study the release of EVs by OA Chondrocytes. The presence of microvesicles on the surface of the cell membrane was identified only in some cells, where considerable dynamisms of the cell membrane together with the shedding of microvesicles occurred in the central region of the plasma membrane and not on the whole cell surface (Figure 1). In particular, TEM analyses of isolated EVs displayed intact vesicles enclosed by the plasma membrane (Figures 2A-2E) and characterized by heterogeneous size, ranging from 52 nm to 707 nm (Figure 2F), confirming the release of both EXOs and MVs by OA chondrocytes. Sometimes, we could identify EVs interspersed in collagen fibers, co-pelletted with EVs at the ultracentrifugation step (Figure 2E).


Moreover, it is known that in the pathogenesis of OA both the chondrocytes and the extracellular matrix (ECM) are fundamental to maintain healthy articular cartilage [13]. Healthy ECM balance is primarily maintained by chondrocytes who produce the main component of matrix: collagen type II and the proteoglycan aggrecan [19]. OA is characterized by the unbalance between synthesis and breakdown of the ECM; the latter is believed to be largely due to MMPs action, in particular MMP-13. [20].
So, we proceeded to verify if other enzyme activity were associated to OA chondrocytes-derived EVs, assuming that they also could have a possible role in the breakdown of the matrix. Zymography assays showed the presence of both gelatinases and plasminogen activators (PAs) (Figure 3). Many lytic bands were evidenced by gelatinase zymography; some of them probably correspond to complexes of gelatinases (100-119 kDa) whilst the others are easily recognized as MMP-9 (88 kDa), pro-MMP-2 (74 kDa) and MMP-2 (63 kDa). Similarly, several lytic bands were present in casein-plasminogen assay probably ascribable to PAI (Plasminogen Activators Inhibitors)-PA complexes (92 kDa), tissue-type Plasminogen (66 kDa) and urokinase-type Plasminogen (44,7-49 kDa).

Conclusion
In conclusion, the data reported in this paper prove that the release of EVs actually occurs in OA chondrocytes; the analysis of their size shows that we have a mixed population consisting of both MVs and EXOs. In addition, to EVs are associated enzymatic activities that may have a role in disease progression.
Acknowledgment
This work was partially supported by Fondazione Cassa di Risparmio della Provincia dellAquila.
